Spring Lead Time Planning: Prototypes to Production
Short answer: Plan for roughly 5–10 working days for a wire-formed prototype, 10–15 working days for a first stamped or CNC-machined prototype batch, and 15–25 working days for a full production run after drawing approval — assuming standard music wire, 302 or 304 stainless, and no new tooling. BQUQ quotes in 12 working hours, so the clock starts the same day you send a drawing. Add 3–7 days if you need passivation, plating, or heat-treat certification. The single biggest schedule risk is not machine time; it is drawing freeze, material availability, and tolerance negotiation before the first coil is wound.
Lead time is not one number. It is a stack of decisions, and most of them are yours, not your supplier's. Engineers who treat spring procurement as a single "how long does it take" question usually get a single vague answer back — and then miss their build date. Engineers who break the schedule into stages get a quote in 12 working hours and a delivery date they can defend in a project review.
This guide breaks spring lead time into its real components, gives indicative day counts for each stage, and shows where you can compress the schedule without paying for air freight.
What actually determines spring lead time?
Five variables dominate. Everything else is noise.
1. Wire or strip material and whether it is in stock. Music wire (ASTM A228), 302/304 stainless, 17-7PH, phosphor bronze, and beryllium copper all behave differently. Exotic alloys and non-standard diameters add days.
2. Geometry complexity. A straight compression spring with closed-and-ground ends is fast. A double torsion spring with custom legs, or a conical spring with variable pitch, needs more setup and more first-article checks.
3. Tolerance and inspection level. A ±0.1 mm free-length tolerance is a production check. A ±0.05 mm load-at-height requirement with a full dimensional report is a metrology project.
4. Finishing. Passivation, zinc plating, powder coat, shot peening, and stress relief all add queue time at outside processors.
5. Documentation. A PPAP-style package, material certs, and batch traceability take longer than a box of springs with a packing list.
The lead time stack, stage by stage
| Stage | Typical duration | Who controls it | Can it be compressed? |
|---|---|---|---|
| RFQ to quotation | 12 working hours | Supplier | Rarely the bottleneck |
| Drawing review and DFM feedback | 1–2 days | Both | Yes — freeze the drawing early |
| Material procurement (in-stock wire) | 0–2 days | Supplier | Yes — design around stock diameters |
| Material procurement (special order) | 5–20 days | Mill | Only by changing the alloy |
| Tooling / coiling setup | 1–4 days | Supplier | Yes — for wire forming, no for new stamping dies |
| First article and inspection | 1–3 days | Supplier | Yes — agree the CTQ list up front |
| Production run | 3–10 days | Supplier | Yes — split into partial shipments |
| Finishing (plating, passivation) | 2–7 days | Outside processor | Partly — combine finishes |
| Final inspection, packing, shipping | 1–3 days | Supplier | Yes — express courier |
Read that table again and notice where the days actually live. It is almost never the coiling machine. It is material, finishing, and the back-and-forth before anyone touches a machine.
Prototype lead time: what should you expect?
Prototypes split into three tiers, and confusing them is the most common source of missed dates.
Tier 1 — Wire-formed prototype (fastest)
If your part can be wound from round wire on a CNC coiler, a prototype is genuinely quick. Typical timeline: drawing review on day 1, wire pulled from stock the same day, coil setup and first article on days 2–3, inspection and dispatch by day 5–7.
This covers most compression springs, simple torsion springs, and extension springs with standard hooks. Expect 5–10 working days end to end.
Tier 2 — Stamped or machined prototype
If the part is a spring clip, a flat spring, or a component with a machined collet feature, you are into tooling. A simple blanking die for a flat spring can be cut in a few days; a progressive die takes longer. CNC-machined prototype parts at ±0.005 mm are typically 10–15 working days including first-article inspection.
Tier 3 — Prototype with special material or finish
Add 5–20 days if the wire is not a stock item, and 2–7 days for plating or passivation. A 17-7PH spring that needs aging after forming will not ship in a week, no matter how simple the geometry looks.
| Prototype type | Typical lead time | Key dependency |
|---|---|---|
| Wire-formed, stock material, no finish | 5–10 working days | Drawing freeze |
| Wire-formed, stock material, passivated | 8–14 working days | Outside processor queue |
| Stamped flat spring, new simple die | 10–15 working days | Die fabrication |
| CNC-machined prototype, ±0.005 mm | 10–15 working days | Programming and inspection |
| Special alloy (17-7PH, BeCu) | 15–30 working days | Mill lead time + heat treat |
Production lead time: where the schedule really goes
Once the prototype is approved, production lead time is mostly a function of quantity, tooling reuse, and finishing.
Small to mid-volume production
For 1,000 to 50,000 pieces on existing tooling, typical production is 3–10 working days of machine time. Add 1–3 days for first-article approval if the drawing changed, and 2–7 days for finishing. Realistic door-to-door: 15–25 working days from approved drawing.
High-volume production
Above roughly 100,000 pieces, the constraint shifts. You may need dedicated tooling, a longer setup, and staged deliveries. Typical total: 25–40 working days for the first production batch, with subsequent batches running in 10–15 working days once tooling exists and material is on a blanket order.
The tooling question
Tooling is a one-time cost and a one-time delay. If your program spans multiple years, amortize the tooling days across the first order only — every later order skips that stage entirely. This is why a second production run is often half the lead time of the first.
Why batch traceability affects your schedule
If your application needs lot-level traceability — wire heat number, coiling date, operator, inspection results — build in an extra 1–2 days for documentation. It is not a manufacturing delay; it is a records delay. It is worth planning for, because retroactively reconstructing a heat number after shipment is usually impossible. Our notes on spring batch traceability cover what to specify on the PO.
How do you compress a spring lead time without paying for air freight?
Seven levers, roughly in order of impact.
1. Freeze the drawing before you request a quote. Every revision after RFQ resets the clock. Send a fully dimensioned drawing with material, finish, tolerances, and inspection requirements on the first pass.
2. Design around stock wire diameters. A 0.1 mm diameter change can turn a 7-day order into a 25-day order. Ask your supplier which diameters they hold.
3. Separate CTQ from nice-to-have tolerances. Over-tolerancing forces extra inspection. If load at 50% deflection is critical but free length is not, say so explicitly.
4. Approve partial shipments. Take the first 500 pieces for your build and let the balance follow. This alone can pull a build date forward by a week.
5. Combine finishes. One plating spec is faster than three. If you can accept passivation instead of a decorative finish, take it.
6. Place a blanket order. Reserving material against a forecast removes the procurement stage from every subsequent release.
7. Use one supplier for the whole family. A single factory running CNC, stamping, springs, and heat sinks in one location removes inter-supplier shipping and re-inspection. BQUQ runs four production lines under one ISO9001 system in Dongguan for exactly this reason.
A worked example
A medical device customer needs 20,000 stainless compression springs with passivation and a dimensional report.
| Week | Activity | Cumulative working days |
|---|---|---|
| Week 1 | RFQ sent Monday, quote returned in 12 working hours, drawing frozen Tuesday | 2 |
| Week 1 | Material pulled from stock, coil setup, first article | 5 |
| Week 2 | First article approved, production run | 10 |
| Week 2–3 | Passivation at outside processor | 15 |
| Week 3 | Final inspection, dimensional report, packing | 18 |
| Week 3 | Dispatch by express courier | 20 |
Twenty working days, roughly four calendar weeks. That is a realistic, defensible number — and it assumes the customer approves the first article within 24 hours. If approval takes a week, the schedule moves a week.
What design choices quietly add weeks?
Some decisions look harmless on a drawing and cost you a fortnight in production.
- Non-standard wire diameter. The single most expensive "small" change.
- Tight free-length tolerance on a long spring. Long springs are harder to hold; this drives inspection time and scrap.
- Closed-and-ground ends on a spring that does not need them. Grinding adds a process step.
- Aggressive solid-height requirements. If your design pushes toward solid height limits, expect iteration. Our solid height guide explains the trade-off between compactness and manufacturability.
- Unspecified material. "Stainless" is not a specification. 302, 304, and 316 behave differently in fatigue and corrosion; the wrong pick costs a redesign. See our spring materials comparison for the trade-offs.
- Plating specified for corrosion without checking the galvanic pair. A plating that looks fine on paper can fail salt spray, forcing a re-run.
How should you plan a schedule you can actually hit?
Work backwards from your build date, not forwards from your PO date.
1. Identify the build date where the springs must be physically present.
2. Subtract shipping (3–7 days by express, longer by sea).
3. Subtract final inspection and packing (1–3 days).
4. Subtract finishing (0–7 days).
5. Subtract production run (3–10 days for mid-volume).
6. Subtract first article approval (1–3 days, but budget for your own review time).
7. Subtract setup and material (1–6 days).
8. Subtract drawing review and quote (1–2 days).
Whatever is left is your latest drawing-freeze date. Write it in the project plan. Most missed spring deliveries trace back to a drawing that was frozen two weeks after the date the schedule silently required.
Buffer sizing
Add 15–20% buffer on the first order of any new part, and 5–10% on repeat orders. First orders carry tooling, first-article, and documentation risk. Repeat orders carry almost none.
Frequently Asked Questions
Q: How long does a custom spring quote take?
A: BQUQ returns quotations in 12 working hours for standard wire-formed springs, provided the drawing includes material, dimensions, tolerances, finish, and quantity. Incomplete drawings take longer because the engineering team has to ask clarifying questions before pricing. Send a fully dimensioned 2D drawing or a 3D step file plus a tolerance table, and the quote typically lands the same working day.
Q: Can I get prototype springs faster than 5 working days?
A: Sometimes, if the part uses stock wire, has simple geometry, and needs no finishing. In that case a wire-formed prototype can ship in 3–5 working days. Anything involving new tooling, special alloy, plating, or heat treatment cannot realistically be compressed below two weeks. Rush options exist but should be treated as exceptions, not as a planning assumption.
Q: Does a larger order quantity always mean a longer lead time?
A: No. Lead time scales with setup and finishing, not linearly with quantity. Going from 5,000 to 50,000 pieces on the same tooling may add only 2–4 days of machine time. The big jumps come from crossing volume thresholds that require new tooling or dedicated equipment, typically above 100,000 pieces. Blanket orders with scheduled releases keep repeat lead times short.
Q: What is the most common cause of spring delivery delays?
A: Late drawing freeze. In most projects the supplier is ready to start but the customer is still finalizing tolerances, material, or finish. The second most common cause is a non-stock wire diameter specified without checking availability. Both are entirely preventable and both are customer-side decisions, not manufacturing constraints.
Q: How does finishing affect the production schedule?
A: Passivation typically adds 2–4 working days; zinc or nickel plating adds 3–7; powder coat adds 3–5. These are outside-processor queues, so they are the least controllable part of the schedule. If your application allows it, choosing a finish your supplier handles in-house — or accepting passivation instead of plating — is the simplest way to shorten total lead time.
