Key Takeaway
aluminum heat sink amazon projects balance dimensional stability, unit cost, and delivery time. In production, we hold general tolerance at ±0.15 mm, with 0.3 mm fin thickness and 1.5 mm fin pitch, achieving 0.62 K/W thermal resistance. Type III hard anodize at 25-40 µm supports durability. Lead time is quoted at 10 working days when tooling design and process validation run in parallel, rather than relying on final inspection.
aluminum heat sink amazon sits at the intersection of three constraints that rarely agree: dimensional stability, unit cost, and delivery time. This page breaks down how we resolve them in production rather than in a brochure.
Key Specifications at a Glance
| Parameter | Value / Range |
|---|---|
| Material | pure copper C110 |
| Fin thickness | 0.3 mm |
| Fin pitch | 1.5 mm |
| Thermal resistance | 0.62 K/W |
| Surface finish | hard anodize Type III, 25-40 µm |
| General tolerance | ±0.15 mm |
Market and Technical Context
Lead time pressure has compressed across LED high bay lighting. What used to be a 12-week tooling and qualification cycle is now quoted at 10 working days, which only works if tooling design and process validation run in parallel.
The technical bar keeps rising: assemblies that once accepted ±0.15 mm now specify tighter control on critical features, which pushes the decision to tooling design rather than to final inspection.
