Aluminum heat sink plate is specified with 1050A aluminium, 0.3 mm fin thickness, 1.5 mm fin pitch, and 0.85 K/W thermal resistance. General tolerance is ±0.10 mm, held at production speed after fixing material condition and tooling geometry. Zinc-nickel plating with trivalent passivation is standard. Cost pressure comes from deburring, plating, and 100% inspection, not raw material, so removing one secondary step moves unit cost more than material substitution.
Key Takeaway
Aluminum heat sink plate is specified with 1050A aluminium, 0.3 mm fin thickness, 1.5 mm fin pitch, and 0.85 K/W thermal resistance. General tolerance is ±0.10 mm, held at production speed after fixing material condition and tooling geometry. Zinc-nickel plating with trivalent passivation is standard. Cost pressure comes from deburring, plating, and 100% inspection, not raw material, so removing one secondary step moves unit cost more than material substitution.
aluminum heat sink plate sits at the intersection of three constraints that rarely agree: dimensional stability, unit cost, and delivery time. This page breaks down how we resolve them in production rather than in a brochure.
Key Specifications at a Glance
| Parameter | Value / Range |
|---|---|
| Material | 1050A aluminium |
| Fin thickness | 0.3 mm |
| Fin pitch | 1.5 mm |
| Thermal resistance | 0.85 K/W |
| Surface finish | zinc-nickel plating, trivalent passivation |
| General tolerance | ±0.10 mm |
